Differential Pinion Seal for Grand Vitara, XL-7, Tracker, Vitara+More 710523

: In stock

:

: Does not apply

Regular price $0.00 $26.15

eBay Differential Pinion Seal for Grand Vitara, XL-7, Tracker, Vitara+More 710523 Fitment Chart: Years Make Model Drive Type Notes 2002-2006 Suzuki XL-7...

QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question
files/payment12.png
eBay
Differential Pinion Seal for Grand Vitara, XL-7, Tracker, Vitara+More 710523

Fitment Chart:

Years Make Model Drive Type Notes
2002-2006 Suzuki XL-7 with Suzuki SK-R Differential
2002-2006 Suzuki XL-7 4WD with Suzuki SK-F Differential
1999-2011 Suzuki Grand Vitara with Suzuki SK-R Differential
1999-2011 Suzuki Grand Vitara 4WD with Suzuki SK-F Differential
1999-2004 Suzuki Vitara with Suzuki SK-R Differential
1999-2004 Suzuki Vitara 4WD with Suzuki SK-F Differential
1996-1998 Suzuki X-90 with Suzuki SK-R Differential
1996-1998 Suzuki X-90 4WD with Suzuki SK-F Differential
1994-1997 Pontiac Sunrunner with Suzuki SK-F Differential
1994-1997 Pontiac Sunrunner with Suzuki SK-R Differential
1992-1993 Asuna Sunrunner with Suzuki SK-R Differential
1992-1993 Asuna Sunrunner with Suzuki SK-F Differential
1989-2004 Chevrolet Tracker with Suzuki SK-R Differential
1989-2004 Chevrolet Tracker 4WD with Suzuki SK-F Differential
1989-1997 Geo Tracker with Suzuki SK-R Differential
1989-1997 Geo Tracker 4WD with Suzuki SK-F Differential
1989-1991 GMC Tracker with Suzuki SK-R Differential
1989-1991 GMC Tracker 4WD with Suzuki SK-F Differential
1989-1998 Suzuki Sidekick with Suzuki SK-R Differential
1989-1998 Suzuki Sidekick 4WD with Suzuki SK-F Differential


Specifications:

Part Category: Differential Pinion Seal
Brand: National
Manufacturer Part Number: 710523
Vehicle Position: Front Outer
Placement on Vehicle: Front Outer
Product Type: Factory Replacement
Type: Differential Pinion Seal
Number of Pieces: 1
Inside Diameter: 1.575
Inside Diameter: 40.000
Thickness: 0.433
Thickness: 11.000
Outside Diameter: 2.843
Outside Diameter: 72.200
Housing Bore (Inch): 2.835
Housing Bore (MM): 72.000
Material: Nitrile
Outside Diameter (Inch): 2.843
Outside Diameter (mm): 72.200
Overall Width with Side Lip (MM): 18.500
Overall Width with Side Lip (Inch): 0.728
Part Description: Oil seal
Series: 710500
Shaft (Inch): 1.575
Shaft (MM): 40.000
Type: 40
Unit of Dimension: Metric
Width (Inch): 0.433
Width (mm): 11.000
Interchange Part Number: 052-4064 09283-40013 09283-40013-000 09283-40022 09283-40022-000
Replaces Part Numbers: 09283-40027 09283-40027-000 14762 19027779 19027779B 710523 NK265
Replacement Part Numbers: 91173283 96057741 96061234
